ITALY

U500 MEMORY PROGRAMMED/SINGLE -CHANNEL

Code No. 0829 .

FEATURES

  • This machine has been designed for production shops which need to change over frequently
  • Its Memory Program technology is “State of the Art” allowing profile data for unlimited frames to be entered or downloaded from a PC
  • Once this information is stored, the operator then “brings up” the next frame to be produced or scans with the optional bar code reader
  • This machine will automatically adjust and production can restart immediately. V-nails can be driven or stacked in up to 10 positions per corner
  • This machine is very fast and easily drives all types of wood, plastic and MDF

TECHNICAL SPECIFICATION OF U500 MEMORY PROGRAMMED/SINGLE -CHANNEL

Frames thickness 5mm to 80mm
Frame width min - max 6 -105 mm
Max dist. Among v-nails 145 mm
Storage capacity n. 220
Pneumatic feed 6-7 bar
Air consumption 4 Nl at 5 bar
V-nails size 7-10-15 mm
V-nails size on request 3-4-5-12 mm
Weight about 135 kgs
Working bench height 960 mm
Overall dimensions 770x770x1500 mm
